Morsø 3112 B

Morsø wood burning stove 3112 B incorporates the best from the classic Morsø design.
3112_usa_frit_600x600

Product description

The Morsø 3100 B series incorporates the best from the classic Morsø design, but takes advantage of the latest combustion principles.

Efficient and environmentally friendly multi-fuel stoves The 3112 B is equipped with riddling grate and ashpan, making it easy to remove ash and clean the stove. It is manufactured using the latest combustion principles with tertiary air supply and meet the most stringent environmental requirements.

It can be fired with wood, briquettes or approved smokeless fuel and is suitable for heating areas of up to 1000 sq. ft.

Technical data

Properties
  • Pre-heated combustion air
  • Airwash system
  • Removable handle
Technical data
  • Radiant Heat
  • 10 year limited warranty
  • Gasketed seams for tight seals
  • Chromium treated internal casting for durab
  • Reversible flue collar
  • Non catalytic burn technology
  • Clean-burning air wash system
  • Secondary air supply
  • Riddling grate system/shaker grate
Fuel
  • Wood
Approvals
  • EPA
Specifications
Maximum Heat 28000 BTU/hr
Log size 12"
Max. Area Heated 1000 ft²
Firebox Dimensions 13 1/4" x 12 1/2"
Firebox volume/capacity 0.9 ft³
Outside air supply Available
Gross Weight 220 lbs
Height 27 1/8"
Width 17 3/8"
Dept 17 3/4"
Flue outlet top 6"
Flue outlet rear 6"
Clearance to combustibles
Basic Clearance using single wall pipe top vent
Stove to side wall 20"
Stove to rear wall 12"
Stove to corner 17"
Basic Clearance using double wall pipe top vent
Stove to side wall 20"
Stove to rear wall 8"
Stove to corner 15"
