Product description

The 3142 B is equipped with a riddling grate and ashpan, making it easy to remove ash and clean the stove.
It is manufactured using the latest combustion principles with tertiary air supply and meets the most stringent environmental requirements.

It can be fired with wood, briquettes or approved smokeless fuel and is suitable for heating an area of up to 1000 sq. ft.

Technical data

Properties
  • Convection Fan
  • Pre-heated combustion air
  • Pre-heated secondary air supply
  • Ash Can
  • Airwash system
  • Tertiary Air
  • Riddling grate system
Technical data
  • 10 year limited warranty
  • Gasketed seams for tight seals
  • Chromium treated internal casting for durab
  • Reversible flue collar
  • Non catalytic burn technology
  • Clean-burning air wash system
  • Secondary air supply
  • Riddling grate system/shaker grate
Fuel
  • Wood
Approvals
  • DIN+
  • EN/N
  • DEFRA
  • EPA
Specifications
Maximum Heat 28000 BTU/hr.
Log size 12"
Max. Area Heated 1000 ft²
Firebox Dimensions 13 1/4 x 12 1/2
Firebox volume/capacity 0.9 ft³
Outside air supply Available
Gross Weight 265 lbs
Height 29 1/8"
Width 20 1/4"
Dept 17 3/4"
Flue outlet top 6"
Flue outlet rear 6"
Clearance to combustibles
Basic Clearance using single wall pipe top vent
Stove to side wall 16"
Stove to rear wall 9"
Stove to corner 13"
Basic Clearance using double wall pipe top vent
Stove to side wall 16"
Stove to rear wall 7"
Stove to corner 11"
